S650 – Bobcat™

The Bobcat® S650 skid-steer loader is a vertical lift path model in the 600 frame size. It offers increased lifting capacity and provides greater forward reach at full lift height for loading trucks. The Tier 4 diesel engine delivers power and performance.



Request a Quote



bobcat logo

More Information

Call for Details.

Specifications

Engine
Engine Cooling Liquid
Emissions Tier (EPA) Tier 4
Engine Fuel Diesel
Horsepower 74 HP
Turbocharged Engine Yes



Performance
Rated Operating Capacity (SAE) 2690 lbs
Tipping Load
5380 lbs
Operating Weight 8061 lbs
Travel Speed
7.1 mph
Travel Speed (2-speed option) 12.3 mph



Capacities
Fuel Tank 23.9 gal



Hydraulic System
System Relief @ Quick Couplers 3500 psi
Auxiliary Std Flow 23 GPM
Auxiliary High Flow 30.5 gal/min



Dimension
Length
136.8 in
Length without Attachment 108.4 in
Length with Standard Bucket 136.8 in
Width 72.1 in
Width (with bucket) 74 in
Height 81.3 in
Height with Operator Cab 81.3 in
Height to Bucket Hinge Pin 124 in
Reach @ Maximum Height 31.5 in
Turning Radius 82.9 in
Wheelbase 45.3 in
