The Bobcat® S590 vertical path skid-steer loader provides more reach at full lift height than a radius lift path loader without sacrificing performance. It features a Tier 4 diesel engine.
S590 – Bobcat™
More Information
Call for Details.
Specifications
| Engine | |
|---|---|
| Engine Cooling | Liquid |
| Emissions Tier (EPA) | Tier 4 |
| Engine Fuel | Diesel |
| Horsepower | 66 HP |
| Turbocharged Engine | Yes |
| Performance | |
|---|---|
| Rated Operating Capacity (SAE) | 2100 lbs |
| Tipping Load |
4200 lbs
|
| Operating Weight | 6593 lbs |
| Travel Speed |
7.4 mph
|
| Travel Speed (2-speed option) | 11 mph |
| Capacities | |
|---|---|
| Fuel Tank | 24.8 gal |
| Hydraulic System | |
|---|---|
| System Relief @ Quick Couplers | 3500 psi |
| Auxiliary Std Flow | 17.1 GPM |
| Auxiliary High Flow | 26.7 gal/min |
| Dimension | |
|---|---|
| Length |
133 in
|
| Length without Attachment | 104.6 in |
| Length with Standard Bucket | 133 in |
| Width | 65.2 in |
| Width (with bucket) | 68 in |
| Height | 77.8 in |
| Height with Operator Cab | 77.8 in |
| Height to Bucket Hinge Pin | 119 in |
| Reach @ Maximum Height | 32.6 in |
| Turning Radius | 79.7 in |
| Wheelbase | 42.6 in |
