Z-135/70 Rough Terrain Articulating Boom – Genie®

  • New X-design drive chassis extends and retracts to provide both stability on the job and a narrow profile for transport
  • Telescoping Jib-Extend™ jib extends from 12 to 20 ft (3.66 to 6.10 m) and provides a 110˚ vertical range of motion
  • 360˚ continuous rotation turntable and 160˚platform rotation for fast, easy positioning
  • Four-wheel drive with full-time positive traction handles rough ground conditions to enhance the smoothness of the ride
  • Four-wheel steer with front-wheel, rear-wheel, crab- and coordinated- steer options available to provide additional maneuverability
  • Full-time positive traction 4WD and four wheel brakes
  • The ALC 1000 electronic control system provides menu-based adjustments for machine and component calibration as well as on-screen multi-language system diagnostics





Request a Quote



Genie Logo

More Information

Z135/70 Genie Rough Terrain Articulating Boom PDF Boom Family Brochure

Specifications

Working Height* 141 ft (43.15 m)
Width – axles extended 16 ft 6 in (5.03 m)
Width – axles retracted 8 ft 2 in (2.49 m)
Horizontal Reach – riser extended 59 ft 2 in (18.03 m)
Horizontal Reach – riser retracted 69 ft 9 in (21.26 m)
Up & Over Clearance – riser extended 75 ft 6 in (23.01 m)
Up & Over Clearance – riser retracted 32 ft 6 in (9.91 m)
Lift Capacity 600 lbs (272 kg)
